Galvanized Venlo Glass Greenhouse: Insulated Tempered Glass Structure for Commercial Cultivation
Our venlo greenhouse structure crafted with hot-dip galvanized steel pipes, the entire framework is assembled using galvanized bolts and self-tapping screws-do not need for welding. This ensures exceptional sturdiness and long-term durability.
Core Specifications
- Span Options: 9.6m / 10.8m / 12m (customizable to meet specific project needs)
- Width: 4.0m / 8.0m (optimized for space utilization and structural stability)
- Gutter Height: 4.0m - 6.0m (accommodates various planting scales and equipment installation)
Structural & Performance Advantages
The Venlo greenhouse structure boasts impressive structural stability and reliable performance: it can stand up to wind loads of 0.5KN/m², snow loads of 0.5KN/m², and a static bearing capacity of 0.5KN/m². It also handles heavy rain like a champ-up to 140mm per hour-so you can count on it even when the weather gets rough.
The main frame is made of top-quality galvanized steel pipes. For hot-dip galvanizing, the zinc coating weight is 220–275g (about 20 microns thick); for electro-galvanizing, it's 150g (15–18 microns thick). This gives it great corrosion resistance and makes the greenhouse last way longer.
As for covering materials, we've got several options for you: polycarbonate hollow sheets, insulated glass, and special aluminum alloy greenhouse glazing. All joints are sealed with aging-resistant EPDM rubber strips, which boosts both thermal insulation and weatherproofing performance.
Key Considerations for Customization
Single-span vs. Multi-span
For large land areas, multi-span greenhouses offer space-saving efficiency with slightly higher investment. The single-span models are more cost-effective and straightforward for smaller operations.
01
Size Determination
Greenhouses with roll-up film windows are recommended to have a length not exceeding 60m. Bay widths (8m, 9m, 9.6m, 10m, 12m) should be selected based on local climate conditions and the growth requirements of target crops, paired with shading and ventilation systems.
02
Roof Design
Round-arch roofs excel in wind resistance and cost-effectiveness, while pointed roofs offer better snow load resistance. Choose based on regional weather patterns.
03
Installation Support
We provide detailed construction drawings and can dispatch professional installation teams. Single-span greenhouses come with a comprehensive installation manual for self-assembly convenience.
04
Our Offerings & Strengths
Beyond galvanized Venlo glass greenhouses, we supply a full range of agricultural structures including hydroponic greenhouses, commercial multi-span greenhouses, film greenhouses, and blackout greenhouses.
Quality assurance is our top priority: we ensuring every greenhouse meets international standards. Whether you're cultivating vegetables, flowers, or high-value crops, our Venlo glass greenhouse delivers the stability, efficiency, and customization needed to max your agricultural productivity.
FAQ
Q: The land area is large. Should we use single sheds or multi-span sheds?
A: If it is related to the plant and can be used, the multi-span shed is more expensive and saves space, and the single shed is simpler and more economical.
Q: How to determine the size of the greenhouse?
A: If there is a roll film window, it is best not to exceed 60m Shading and shading system, need to pay attention to the reasonable allocation of bays Span width 8, 9, 9.6, 10, 12m. It is highly necessary to consider the climatic conditions and the growth requirements of the planted plants"
Q: Should you choose a round arch or a pointed roof?
A: The round arch is better against wind. The spire is better against snow. Round arch is cheaper
Q: How to install the greenhouse?
A: Can send out drawings to send workers, single shed recommends that customers install by themselves, can produce a detailed installation guide manual
Q: How many 300-square-meter greenhouses can be installed in a cabinet?
A: It can be installed with about 18 seats of 32 arches and about 10 seats of 60
Q: Thickness of zinc layer of hot-dip galvanizing/thickness of zinc layer of galvanized zinc
A: 220-275g, 20μ/150g, 15 -18μ
